XSERIES 1270 - 2 Person Mobile Grabber
The XSERIES 1270 - 2 Person Mobile Grabber is a robust and versatile solution for your elevated worksite needs, designed with maximum efficiency and safety in mind. Weighing in at 6700 lbs, this heavy-duty unit offers a remarkable max working height of 45 feet and can be compactly folded to a height of 8 feet 3 inches for convenient transportation and storage. Its solid frame, measuring 5 feet 9 inches in width, can extend to a working frame width of 10 feet 9 inches, providing a stable and secure platform for two users. The overall length of the unit is 20 feet 10 inches, ensuring ample space for maneuvering and working comfortably. With a max anchor point capacity of 310 lbs and a max arm reach out of 10 feet 4 inches, the XSERIES 1270 delivers unparalleled reach and support for various tasks.
Equipped with an electric-driven hydraulic system powered by a reliable 12V battery, the XSERIES 1270 offers smooth and precise movements. The hydraulics fluid system, using Mobi DT10 Excel 22 with a capacity of 12.5 gallons, ensures optimal performance and longevity. The unit's four manually adjustable jacks provide exceptional stability on uneven terrain, enhancing safety and operational efficiency. The actuating method is seamlessly controlled via a remote with a 15-foot cord, granting users the flexibility to operate the machine from a safe distance. This intuitive control system makes the XSERIES 1270 a user-friendly choice for both novice and experienced operators.
Safety and convenience are paramount with the XSERIES 1270 - 2 Person Mobile Grabber. Designed to accommodate a maximum of two users, this mobile grabber is ideal for a wide range of applications, from construction and maintenance to inspection and installation tasks. Its minimum working height of 2 feet ensures that even the most accessible tasks can be undertaken without compromising stability. The powerful 12V battery provides consistent power, ensuring that the mobile grabber is ready to tackle any job, big or small. Whether you're working on a high-rise building or conducting routine maintenance, the XSERIES 1270 offers the reliability and performance you need to get the job done efficiently and safely.
Key Features:
- Weight: 6700 lbs
- Max Working Height: 45 ft
- Min Working Height: 2 ft
- Max. Folded Height: 8 ft 3 in
- Frame Width: 5 ft 9 in
- Working Frame Width: 10 ft 9 in
- Max Arm Reach Out: 10 ft 4 in
- Overall Length: 20 ft 10 in
- Max. Anchor Point Capacity: 310 lbs
- Max. Allowable Users: 2
- Actuating Method: Electric-driven Hydraulic System
- Controls: Remote (15 ft cord)
- Power Source: 12V Battery
- Outrigger System: 4 Manually Adjustable Jacks
- Hydraulics Fluid Type: Mobi DT10 Excel 22
- Hydraulics Fluid Capacity: 12.5 Gallons
